LED vgradna svetila

LED vgradna svetila ustvarjajo mehko svetlobo ter globino. LED vgradna svetila ustvarijo iluzijo, da prostor zgleda večji. Podajo se v vsak dom in njihova svetloba je prijetna in mehka. Vgradne luči so prilagodljive in so primerne tudi za osvetlitev okolice. Vgradne LED luči imajo zatemnitvene učinke, ki jih lahko tudi nadzorujemo s pomočjo LED kontrolnih sistemov. Primerne so za vse notranje prostore in zunanjo uporabo. Zagotovijo veliko količino svetlobe, ki pa je zelo podobna naravni svetlobi. Vgradna LED svetila ne bleščijo ali oddajajo neprijetnega leska. Primerna pa so tudi za umetniška dela in dekorativne namene.

Katalog LED vgradnih svetil



ITEM SIZE WATT HOLE SIZE LED CHIP LEDS QTY CRI LUMEN COLOR COLOR TEMPERATURE BEAM ANGLE WORKING EFFICIENCY IP GRADE MATERIAL Non-dim PRICE € DIM PRICE €
LED-DLD1 ф102*44.1mm 3W 80mm 5730 6pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 5,24 6,27
LED-DLD2 5W 80mm 5730 10pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 5,70 8,36
LED-DLD3 ф112*49mm 7W 100mm 5730 14pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 6,38 14,81
LED-DLD4 9W 100mm 5730 18pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 7,26 15,51
LED-DLD5 ф146*75.3mm 9W 125mm 5730 18pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 9,02 17,29
LED-DLD6 12W 125mm 5730 24pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 9,90 17,60
LED-DLD7 ф190*54.9mm 15W 170mm 5730 30pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 13,64 25,45
LED-DLD8 18W 170mm 5730 36pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 14,48 26,07
LED-DLD9 ф235*56.9mm 24W 215mm 5730 48pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 20,24 30,91
LED-DLD10 36W 215mm 5730 72pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 aluminium 23,10 40,92



ITEM SIZE WATT HOLE SIZE LED CHIP LEDS QTY CRI LUMEN COLOR COLOR TEMPERATURE BEAM ANGLE WORKING EFFICIENCY IP GRADE MATERIAL Non-dim PRICE € DIM PRICE €
LED-DLCOB1 ф90*54mm 3W 80mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 6,82 7,92
LED-DLCOB2 ф100*50mm 5W 80mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 8,47 11,22
LED-DLCOB3 ф130*58mm 7W 100mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 9,68 18,13
LED-DLCOB4 ф160*66mm 10W 110mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 14,08 22,53
LED-DLCOB5 ф190*70mm 20W 175mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 19,76 32,05
LED-DLCOB6 ф230*85mm 30W 210mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 27,72 47,76
LED-DLCOB7 ф280*85mm 40W 260mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 48,29 65,85



ITEM SIZE WATT HOLE SIZE LED CHIP LEDS QTY CRI LUMEN COLOR COLOR TEMPERATURE BEAM ANGLE WORKING EFFICIENCY IP GRADE MATERIAL Non-dim PRICE € DIM PRICE €
LED-DLSMD1 ф90*54mm 3W 80mm 5730 6pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 5,32 6,36
LED-DLSMD2 ф100*50mm 5W 80mm 5730 10pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 7,28 9,94
LED-DLSMD3 ф115*50mm 7W 100mm 5730 14pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 8,71 17,16
LED-DLSMD4 ф130*58mm 9W 110mm 5730 18pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 10,23 18,68
LED-DLSMD5 ф145*70mm 9W 125mm 5730 18pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 11,81 20,24
LED-DLSMD6 ф160*66mm 12W 140mm 5730 24pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 12,98 21,43
LED-DLSMD7 ф180*65mm 15W 160mm 5730 30pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 15,00 27,21
LED-DLSMD8 ф190*70mm 18W 175mm 5730 36pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 15,82 28,03
LED-DLSMD9 ф230*85mm 24W 210mm 5730 48pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 22,22 33,22
LED-DLSMD10 ф280*100mm 36W 260mm 5730 72pcs >80 95lm/W W/WW/NW 2700K-7500K 120° >85% IP20 dia-casting 43,12 61,45



ITEM SIZE WATT HOLE SIZE LED CHIP LEDS QTY CRI LUMEN COLOR COLOR TEMPERATURE BEAM ANGLE WORKING EFFICIENCY IP GRADE MATERIAL Non-dim PRICE € DIM PRICE €
LED-DLDLD1 ф90*53mm 3W 75mm Epistar 3pcs >80 95lm/W W/WW/NW 2700K-7500K 120° 85% IP20 Fin heatsink + P 7,37 8,18
LED-DLDLD2 ф102*66 mm 7W 85mm Epistar 7pcs >80 95lm/W W/WW/NW 2700K-7500K 120° 85% IP20 Fin heatsink + P 13,42 21,16
LED-DLDLD3 ф145*78 mm 15W 130mm Epistar 15pcs >80 95lm/W W/WW/NW 2700K-7500K 120° 85% IP20 Fin heatsink + P 25,39 36,54
LED-DLDLD4 ф195*105 mm 24W 175mm Epistar 24pcs >80 95lm/W W/WW/NW 2700K-7500K 120° 85% IP20 Fin heatsink + P 40,88 50,12
LED-DLDLD5 ф240*106 mm 36W 225mm Epistar 36pcs >80 95lm/W W/WW/NW 2700K-7500K 120° 85% IP20 Fin heatsink + P 56,56 72,82



ITEM SIZE WATT HOLE SIZE LED CHIP LEDS QTY CRI LUMEN COLOR COLOR TEMPERATURE BEAM ANGLE WORKING EFFICIENCY IP GRADE MATERIAL Non-dim PRICE € DIM PRICE €
LED-DLDLD6 ф100*40mm 5W 90mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 6,82 10,01
LED-DLDLD7 ф130*50mm 10W 115mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 9,90 18,33
LED-DLDLD8 ф165*50mm 15W 145mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 13,05 25,26
LED-DLDLD9 ф190*50mm 20W 170mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 15,97 27,08
LED-DLDLD10 ф220*60mm 25W 200mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 20,02 39,91



ITEM SIZE WATT HOLE SIZE LED CHIP LEDS QTY CRI LUMEN COLOR COLOR TEMPERATURE BEAM ANGLE WORKING EFFICIENCY IP GRADE MATERIAL Non-dim PRICE € DIM PRICE €
LED-DLDLD11 ф90*42mm 3W 75mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 6,23 7,55
LED-DLDLD12 ф105*42mm 5W 95mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 7,68 10,87
LED-DLDLD13 ф120*42mm 7W 105mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 8,54 11,73
LED-DLDLD14 ф130*42mm 10W 110mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 10,43 19,38
LED-DLDLD15 ф145*42mm 12w 120mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 11,88 20,86
LED-DLDLD16 ф165*60mm 15W 150mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 14,34 23,94
LED-DLDLD17 ф190*60mm 20W 170mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 18,33  30,49
LED-DLDLD18 ф220*60mm 30W 200mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 22,79 42,79
LED-DLDLD19 ф300*100mm 40W 280mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 47,26 64,17



ITEM SIZE WATT HOLE SIZE LED CHIP LEDS QTY CRI LUMEN COLOR COLOR TEMPERATURE BEAM ANGLE WORKING EFFICIENCY IP GRADE MATERIAL Non-dim PRICE € DIM PRICE €
LED-DLDLD20 ф165*60mm 15W 140mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 14,34 23,94
LED-DLDLD21 ф190*70mm 20W 170mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 17,56 29,70
LED-DLDLD22 ф220*73mm 30W 200mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 22,26 42,26


ITEM SIZE WATT HOLE SIZE LED CHIP LEDS QTY CRI LUMEN COLOR COLOR TEMPERATURE BEAM ANGLE WORKING EFFICIENCY IP GRADE MATERIAL Non-dim PRICE € DIM PRICE €
LED-DLDLD23 ф90mm*42mm 3W 75mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 6,23  7,28
LED-DLDLD24 ф105mm*42mm 5W 105mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 7,70 10,36
LED-DLDLD25 ф130mm*42mm 10W 110mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 10,54 18,44
LED-DLDLD26 ф165mm*60mm 15W 140mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 14,34 23,94
LED-DLDLD27 ф190mm*70mm 20W 170mm Epistar 1pcs >80 95lm/W W/WW/NW 2700K-7500K 60° >85% IP20 dia-casting 18,33 30,49

PRICE EXCL. VAT   EX WORK MARIBOR – SLOVENIA
WARRANTY: STANDARD 2 YEARS
